Air-cooled Chiller RF 120

Air-cooled Chiller RF 120

Category : Air-cooled Chiller

Air-cooled Chiller is a device that cools down with condensing air. Thanks to the fans on it, the refrigerant going through condenser cools down the liquid. Air-cooled Chiller is a system located generally on the roof which is airy in the place or establishment where it is installed. This chiller models are located on the places where the water efficiency is low.

Product Description

Air-cooled Chiller is a device that cools down with condensing air. Thanks to the fans on it, the refrigerant going through condenser cools down the liquid. Air-cooled Chiller is a system located generally on the roof which is airy in the place or establishment where it is installed. This chiller models are located on the places where the water efficiency is low.

Air-cooled Chiller cooling groups can be used in various configurations as a single unit or split units. It provides wide product range from the products with marginal capacity to a-few-tones-models used in big trade buildings.

OUR TECHNICAL DATA
AIR COOLED SCROLL COMPRESSOR CHILLERS
Model Model Refrigerant R 407 C RF10 RF16 RF20 RF25 RF30 RF35 RF40 RF55 RF60


PERFORMANCE VALUES FOR REFERENCE CONDITION 1 (Two/Twi= 15 °C / 20 °C T ai = 25 °C, R 407 C)
Cooling Capacity kW 15,6 26,0 33,3 40,2 47,8 52,0 66,5 80,5 95,6
  kcal/h 13.448 22.388 28.609 34.623 41.145 44.776 57.218 69.247 82.291
Total Compressor Power kW 2,7 4,3 5,7 6,9 8,2 8,5 11,4 13,9 16,4


PERFORMANCE VALUES FOR REFERENCE CONDITION 2 (Two/Twi=15 °C / 20 °C T ai = 32 °C, R 407 C)
Cooling Capacity kW 13,7 22,8 28,9 35,3 41,7 45,7 57,8 70,7 83,5
  kcal/h 11.822 19.643 24.866 30.399 35.905 39.287 49.732 60.797 71.811
Total Compressor Power kW 3,0 5,2 6,6 7,7 9,2 10,3 13,1 15,4 18,3


PERFORMANCE VALUES FOR REFERENCE CONDITION 3 (Two/Twi=7 °C / 12 °C T ai = 35 °C, R 407 C)
Cooling Capacity kW 9,6 16,5 20,4 25,0 29,3 33,0 40,8 50 65
  kcal/h 8.269 14.214 17.553 21.485 25.236 28.428 35.105 42.969 57000
Total Compressor Power HP 5 6 7 8 10 12 15 10×2 12×2
K Number of Compressors pcs. 1 1 1 1 1 1 1 2 2
Number of Fans / Fan Diameter pcs. / mm 1 x Ø500 2 x Ø500 2 x Ø500 2 x Ø500 2 x Ø630 2 x Ø630 2 x Ø630 4 x Ø630 4×6
Çekilen Toplam Güç Total Power kW 4,2 7,2 8,6 10,8 12,5 14,3 17,1 19,4 22,8
Total Current A 9,6 17,0 18,9 24,7 27,2 33,9 37,7 39,9 44,9
Energy Efficiency Ratio kW / kW 2,29 2,30 2,38 2,32 2,35 2,30 2,38 2,57 2,58
Sound Pressure Level(10 m) dBA 48 51 51 53 53 54 54 43 43
Required Evaporator Water Flow m3/h 3 4 6 7 8 9 12 14 16
Pump Power (For 3 bars) kW 1,1 1,2 1,2 1,2 1,2 1,5 2,2 2,2 2,2
Tank Volume Lt. 110 180 180 230 240 280 330 370 500
